AUTOMATIC CARTRIDGE DISPENSING SYSTEM

Drum press/ pail extruder/ pail pump is a simple, robust single component dispensing system can easy pump out a wide range of materials. It offers chemical resistant, hardened parts making it both durable and low maintenance.
This single component system is heavy duty and it easily dispenses fluids or adhesives.
It offers a 25 kg and 250 kg tank and can dispense materials up to 1.5 lac cps viscosity.
This system is built on a portable cart and with simplicity in mind, making it affordable, reliable, and easy-to-use. It can simultaneously run two hand guns allowing for double the output.
Use this system with a wide range of viscosity materials including silicone, polyurethane and polysulfide.

FEATURES –

  • High flow rate pumps and guns
  • Priming piston (shovel) type suction for high viscosity fluids
  • Superior quality spares to reduce maintenance cost
  • Auto shut off for pumps
  • Facility for twin pall switchover system
  • Drum capacity 20 lit and 200
  • Custom built system for more drum capacity with special features
  • Separately heating system with PLC base control
  • Temperatures of individual heated parts can be visible on HMI Display with special security features
  • Hydraulic Stroke count possible to check per day material consumption (optional)
  • Air consumption monitoring (optional)
  • These are equipped with medium duty or heavy-duty range of pumps and are suitable for semi-solid and pasty materials

Specifications –



Type



55.275 D



75:210 D







Size

25 kg

200kg

Ratio

55:1

75:1

Output per Cycle

275cc

210cc

Air Motor Piston

300mm

300mm

Stroke Length mm

120mm

120mm

Recommended Dispensing Spray

Volume per Min.

2.75 lit.

2.10 lit.

Air Inlet Pressure max.

6 bars

6 bars

Output Pressure max.

330 bars

450 bars

Air Consumption

N letter / min max

1100

1100

Material that can be used:

  • Glue
  • Adhesive
  • Epoxy
  • Resin
  • Grease
  • Anaerobic
  • Pasty material
  • Chemical



We offer the following dispensing methods:
1.Manual dispensing
2.Automatic stationary.
3.Conveyor dispensing.



Fig: Cartridge dispensing and push cap slides with conveyorized system



Fig: Push cap slides and bottom cartridge pusher with conveyor



Fig: Top view of System





Fig: Bottom automatic cartridge pusher
